Slip Form Paver
We stand strong as a reliable Slip Form Paver manufacturer in India, committed to unmatched and high-performance machines to achieve continuous, accurate, and quality paving of concrete roads, highways, airport runways, and lining of canals. The slip-form technology differs significantly in terms that the conventional fixed-form paving can use a moving mold that shapes and finishes concrete during a single pass that dramatically increases the speed, precision, and finish. Our machine is durable in frame construction, has automated grade and slope control, and hydraulically adjustable sections of mold to accommodate different widths of pavements and depths. It provides excellent edge control, great compaction, and smooth surface finish even on large-scale infrastructural works. The engine delivers high torque and a refined control system that works constantly in harsh environments on sites with minimal labour input.
In Vinayak Equipment, slip-form pavers are also designed to take advantage of strength, precision, and automation that satisfy the world’s quality requirements. The machine has pre-installed vibrators, tamper bars, and augers, as well as oscillators, to ensure even distribution and consolidation of the concrete. Its control panel is PLC-based, and it can be tracked in real-time and manipulated parameters associated with the paving, such as speed, alignment, and cross-slope parameters. This equipment has customizable settings, and its curb, gutter, median, and barrier wall models make it very handy to road and infrastructure contractors. The complete track mounting makes it easily maneuvered even on rough terrains, and the modular structure tends to be easily transported and deployed. Our Slip Form Paver can be applied in expressways, airports, cities, and municipalities to achieve long-lasting and structurally sound pavement at a low labour cost.
- Continuous, high-speed concrete paving
- Adjustable mold for varying widths and profiles
- PLC-based auto control with slope & grade sensors
- Heavy-duty crawler tracks for smooth movement
- Integrated vibrators and augers for compaction
- Suitable for roads, runways, curbs, and medians
- Customizable mold sizes and attachments
- Concrete road and expressway paving
- Airport runway and taxiway construction
- Canal and irrigation channel lining
- Urban street and highway median construction
- Barrier wall and curb paving
- Industrial pavement and factory flooring projects
Paving Width | 2.5 to 12 meters (customizable) |
---|---|
Paving Thickness | Up to 450 mm |
Engine Power | 150–200 HP (diesel) |
Track System | Crawler-mounted with rubber pads |
Control System | PLC-based auto grade and slope control |
Vibrators | Electric / Hydraulic (variable speed) |
Augers & Oscillators | Included for concrete distribution |
Travel Speed | Up to 18 m/min |
Molds | Custom mold for curb, barrier, gutter, etc. |
Transportability | Modular design for easy shifting |
